Description

Peroni SC-T 1000

Automatic grooving & corner cutting inline

An automated rotating grooving machine designed for paper converting and luxury packaging. Manufactured in Italy, it is heavily utilized in the production of rigid boxes, folders, and display items to create precise V- or U-shaped grooves in cardboard blanks


Features

  • Automatic Grooving (V & U Cuts): Capable of making precise V-shaped grooves (from 80° to 130°) and U-shaped grooves in cardboard and greyboard.
  • Inline Corner Cutting: Performs exact four-corner cutting/punching in a single pass.
  • Double Feeder System: Equipped with an automatic double feeder with a storage magazine for continuous, high-speed board handling.
  • High Production Output: Capable of speeds up to 60 cycles/minute or up to 8 grooves per cycle, depending on board size and thickness.

If you require more information or a brochure, please contact us direct on 01582 562518

Specifications

ManufacturerPeroni Ruggero
ModelSC-T 1000
Year2026
ConditionNew
Stock Number000000000
Cardboard sizesmin. 130 x 130 mm – max. 700 x 700 mm max. 1.040 mm (width) x 700 mm, if manually fed max. 950 mm (width) by double feeder
Cardboard thicknessmin. 1 mm – max. 4 mm
ToolsNr.8 “V” shape groove from 80° to 130° “U” shape groove from 6 mm to 8 mm (optional)
Wheelbasemin. 70 mm – no limits if grooving blades are installed on two bars
Mechanical speed40m/min. (from 40 to 260 pcs/min. according to the cardboard size)
